TAT140 Tracker

Stay Connected to Your Vehicle, Anywhere.

tat140 track

Tat140 – Tracking made simple

Compact, Versatile Vehicle Tracker

The TAT140 is all about simplicity and reliability.

A lightweight, easy-to-install tracker designed for individuals who want reliable, real-time tracking for their vehicles or smaller assets.

BUY NOW

Benefits of vehicle.watch

Always Informed With Live Data

Get real-time updates on your vehicle’s exact location, so you can check in anytime and stay in control.

Boundaries for Peace of Mind

Create virtual zones and receive alerts when your vehicle enters or exits them, helping you monitor movement effortlessly.

Instant SMS
Alerts

Receive instant notifications straight to your phone, so you’re always aware of any unexpected activity or movement.

Monitor From Anywhere

Access live tracking and location updates from your phone, tablet, or computer, no matter where you are in the world.

How Does The TAT140 Work?

Using the TAT140 is straightforward, with no complicated setup or steep learning curves.

Step 1: Install Easily – Place the TAT140 discreetly in your vehicle or on your asset.

Step 2: Log Into Your Account – Log into your vehicle.watch account to start tracking.

Step 3: Set Up Geofences – Set up boundaries to get live notifications when it enters/leaves a location.

vehicle.watch

Who Is The TAT140 For?

The TAT140 is designed for individuals who need a simple, reliable, and affordable way to keep track of their vehicles or smaller assets. Whether you’re safeguarding your car, motorcycle, or valuables, this compact tracker is perfect for everyday personal use.

Car Owners

Keep an eye on your car to ensure it’s exactly where it should be, whether parked or on the move.

Parents of New Drivers

It can be scary when your children get their first car! Monitor their location for peace of mind when they’re out on the road.

Asset Protectors

Perfect for tracking smaller valuables like trailers, scooters, or equipment that you want to keep safe.

Anyone and Everyone!

At the end of the day, the TAT140 is perfect for anyone who wants to keep an eye on their vehicles/assets, and get notifications if they move unexpectedly.

BUY NOW

TAT140 Specifications

Live GPS Tracking
Geofencing
Accelerometer Sensor
GNSS, Bluetooth ® LE sensors support
Recovery mode
Periodic tracking on stop / on move
SMS Notifications
GNSS: GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS
Receiver: 33/99 acquisition channels
Tracking Sensitivity: -165 dBM
Position Accuracy: < 2.5 m CEP
Technology: LTE Cat 1, GSM
2G bands:
TAT140-QJIBO: EG915U-EU GSM: B2/B3/B5/B8
TAT140-QKIB0: EG915U-LA GSM: B2/B3/B5/B8
4G LTE bands
TAT140-QJIBO: EG915U-EU LTE-FDD: B1/B3/B5/B7/B8/B20/B28
TAT140-QKIB0: EG915U-LA LTE-FDD: B2/B3/B4/B5/B7/B8/B28/B66
4G LTE bands
TAT140-QJIBO: EG915U-EU LTE-FDD: B1/B3/B5/B7/B8/B20/B28
TAT140-QKIB0: EG915U-LA LTE-FDD: B2/B3/B4/B5/B7/B8/B28/B66
Data transfer
LTE FDD (CAT 1): Max. 10 Mbps (DL) / Max. 5 Mbps (UL);
GSM (GPRS): Max. 85.6 Kbps (DL) / Max. 85.6 Kbps (UL)
Transmit power
Class 4 for GSM850/900: 33±2dBM
Class 1 for GSM1800/1900: 30±2dBM
Class 3 for LTE-FDD: 23±2dBM
Data support: SMS (TEXT), Network protocols (TCP,UDP,TLS, EGTS, MQTT)
Internal battery: Extremely low self-discharge Li-SOCl2 swappable, non-rechargeable battery, 7,2V 2200mAh
Battery life

Up to 5 years
 (when used as a backup tracker only via Bluetooth®)*
Up to 4 years (1 LBS – cell towers report per day)*
Up to 3 years (1 GNSS report per day)*

*Battery life estimates are influenced by many factors such as outdoor temperature, frequency of reporting, installation, and orientation of the device, network coverage, additional functionalities (like Bluetooth® scanning enabled) and more.
Operating temperature (with battery): -35 °C to +75 °C
Storage temperature (with battery): -40 °C to +85 °C (Recommended max. 30°C)
Operating temperature (without battery): -20 °C to +60 °C
Operating humidity: 5% to 95% non-condensing
Ingress Protection Rating: IP68
Ingress Protection Rating: IP68
Battery discharge temperature: -60 °C to +85 °C
Battery storage temperature: Recommended max. 30°C
Dimensions: 78 x 63 x 28 mm (L x W x H)
Weight: 115g (with 2 cells battery)

Q: How easy is the TAT140 to install?

A: Extremely easy! You can set it up in minutes with no tools or professional help required.

Q: Can I use the TAT140 for more than one vehicle?

A: Absolutely! Its compact design makes it easy to move between vehicles or assets as needed.

Q: Do I need a smartphone to use the TAT140?

You can monitor your vehicle using any devices with a connection to the internet!


Secure Your Vehicle Today

Take control of your vehicle’s safety with the TAT140. Whether you’re protecting your car, monitoring your teen’s first vehicle, or securing small assets, the TAT140 is your trusted tracking companion.
